Legacy Equipment

STR Open-Frame Process Refrigerated Dryers

The unique nano direct expansion, dual action, shell and finned tube heat exchangers provide very low pressure drop and superior dew point performance because of the copper tube aluminum-finned design. This design incorporates both primary and secondary heat transfer surface areas, which eliminates the need for a mechanical separator. All of this translates into one of the most efficient and cost-saving products on the market, with one of the lowest pressure drops in the industry.

Product Documentation

nano-purification solutions product brochure with equipment details

STR Open-Frame Refrigerated Process Dryers

Product Brochure

Filename
EN-R3-STR-brochure-open-frame-refrigerated-process-dryers.pdf
Size
3 MB
Format
pdf
View
ISO compressed air quality standards brochure

ISO Compressed Air Quality Standards

Support Brochure

Filename
EN-ISO-brochure-compressed-air-quality-standards.pdf
Size
7 MB
Format
pdf
View

STR Open-Frame Refrigerated Dryers - R404a

Material Safety Data Sheet

Filename
EN-VF-AES-refrigerated-dryers-R404a-MSDS.pdf
Size
485 KB
Format
pdf
View

STR Open-Frame Refrigerated Dryers - R407c

Material Safety Data Sheet

Filename
R1-NXC-msds-cycling-refrigerated-dryers-R407C.pdf
Size
223 KB
Format
pdf
View
nano equipment user guide

STR Open-Frame Refrigerated Process Dryers

User Guide

Filename
R3-STR-user-guide-open-frame-process-refrigerated-dryers.pdf
Size
2 MB
Format
pdf
View

Specifications of these models

Dryer Model

Inlet & Outlet

Rated Flow at 100 psig

Pressure Drop

Compressor(s)

Absorbed Power

NPT(M) / Flg

scfm

psi

qty

hp

Type

kW

amps

STR 1250-A

3”

1250

1.6

1

8

scroll

10.4

16.4

STR 1500-A

3”

1500

2.0

1

9

scroll

11.8

17.5

STR 1500-W

3”

1500

2.0

1

7.5

semi-hermetic

7.5

14.1

STR 1750-A

4”

1750

2.8

1

10

scroll

13.9

17.8

STR 1750-W

4”

1750

2.8

1

7.5

semi-hermetic

7.5

14.1

STR 2000-A

4”

2000

3.5

2

12

scroll

15.1

18.6

STR 2000-W

6”

2250

4.4

1

10

semi-hermetic

10.7

20

STR 2500-A

6”

2500

1.5

2

16

scroll

15.1

18.6

STR 2500-W

6”

2500

1.5

1

10

semi-hermetic

10.7

20

STR 3200-A

6”

3200

2.5

2

20

scroll

27.7

35.6

STR 3200-W

8” Flg

3200

2.5

1

15

semi-hermetic

15.1

29

STR 4000-A-RC

8” Flg

4000

2.8

1

28

semi-hermetic

30.5

45.8

STR 4000-W

8” Flg

4000

2.8

1

20

semi-hermetic

20.1

53.6

STR 5000-A-RC

8” Flg

5000

4.2

1

35

semi-hermetic

38.5

57.5

STR 5000-W

8” Flg

5000

4.2

1

30

semi-hermetic

38.3

48.1

STR 6250-A-RC

8” Flg

6250

4.5

1

40

semi-hermetic

44.4

65.2

STR 6250-W

8” Flg

6250

4.5

1

35

semi-hermetic

42.3

53.2

STR 7500-W

8” Flg

7500

6.5

1

40

semi-hermetic

37.5

79.3


Specifications

Heat exchanger type

shell and finned tube

Design operating pressure

0 to 150 psig

Design /maximum inlet air temperature range

100°F / 120°F

Design /maximum ambient temperature range

100°F / 110°F

Condenser cooling options

air-cooled (-A) or water-cooled (-W)

Refrigerant type

refrigerant type R404A or R407C (dependent on model)

Control panel enclosure

NEMA 1

Power supply requirements

460V/3Ph/60Hz

(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
