Legacy Equipment

Medical Vacuum

Our medical vacuum filters are specifically designed to eliminate solid, liquid and bacterial contamination from medical vacuum systems, while meeting ISO 7396-1, HTM 02-01 and 2018 revision of NFPA 99 (5.1.3.7.4) standards. The unique design provides maximum filtration performance while minimizing pressure drop for optimum energy efficiency.

Key Specs:

Flow Rate

2.1 to 156 scfm

Connection

1/4” to 3“ NPT

Filtration

0.01 micron

Product Documentation

nano-purification solutions product brochure with equipment details

F1 NMV - Brochure

Filename
EN-F1-NMV-brochure-medical-vacuum-filters.pdf
Size
650 KB
Format
application/pdf
View
ISO compressed air quality standards brochure

ISO Compressed Air Quality Standards

Filename
EN-ISO-brochure-compressed-air-quality-standards.pdf
Size
7 MB
Format
application/pdf
View
nano-purification solutions product brochure with equipment details

Safe Quality Food (SQF) Standards

Filename
EN-SQF-brochure-safe-quality-food-air-quality-standard.pdf
Size
848 KB
Format
application/pdf
View

Features

Manual valve and sterilizable glass drain flask are included as standard

Allows close coupling of filters to simplify installation and maintenance

Drop-fit element engages the bowl to prevent vibration, improving stability and drainage

Specifications of our models

Filter Model

Replacement Element Part no.

Inlet &

Outlet (1)

Exhaust Flow Rate (2)

(vacuum displacement)

NPT

scfm

Nm3/h

NMV 0025

E 0025 MV

¼”

2.1

3.5

NMV 0035

E 0035 MV

⅜”

2.9

5.0

NMV 0050

E 0050 MV

½”

4.1

7.0

NMV 0070

E 0090 MV

½”

7.1

12

NMV 0085

E 0090 MV

¾”

8.8

15

NMV 0125

E 0135 MV

¾”

14.7

25

NMV 0135

E 0135 MV

1”

19.4

33

NMV 0175

E 0175 MV

1”

26.5

45

NMV 0280

E 0325 MV

1 ¼”

35.3

60

NMV 0325

E 0325 MV

1 ½”

41.2

70

NMV 0400

E 0450 MV

1 ½”

55.9

95

NMV 0450

E 0450 MV

2”

70.6

120

NMV 0700

E 0700 MV

2”

103

175

NMV 0850

E 1000 MV

2 ½”

112

190

NMV 1000

E 1000 MV

3”

118

200

NMV 1250

E 1250 MV

3”

132

225

NMV 1500

E 1500 MV

3”

156

265

Specifications

NMV 0025 to 0050

NMV 0070 to 1500

Vacuum Indicator

NDV 50

NDV 1500

Condensate Drain (included) (3)

MLF 100

MLF 250

Design Operating Pressure Range

Full Vacuum to 7 psig / 0.5 bar

Filter Housing Material

Cast aluminum with e-Coat™ & powder top coat finish

Element Performance

MV

DOP Particle Removal Efficiency (4)

> 99.995%

Pressure Drop - Clean

0.44 psid / > 0.0 bar

Pressure Drop - Recommended Replacement

1.5 psid / 0.1

Design Operating Temperature Range

35 to 140°F / 2 to 60°C

Flow Direction Through Element

Outside to Inside

Maximum Element Life

6 months or 1000 hours

(1) inlet and outlet connections are NPT threaded to ANSI B2.1

(2) free air conditions when operating at atmospheric pressure. For vacuums refer to the vacuum correction factor table above

(3) includes manual valve and sterilizable glass drain flask

(4) as specified in HTM 02-01 medical gas pipeline systems

(5) technical specifications subject to change without notice. Direct inquiries to support or contact 704.897.2182
