This product can be mounted to a wall or skid or any location that requires breathing air on a regular basis.
Key Specs:
Flow Rate
85 to 297 Nm3/h
Connection
½" BSPP
STANDARDS
EN12021
Product Documentation
- Brochures
- User Guides
- Worksheet
Features
This panel is built with multiple connections for multiple users, and contains a water separator, 0.01 micron coalescing with drain and activated carbon adsorber to remove moisture, oil aerosols odors, and taste to 0.003 ppm.
Integrated CO monitor included as standard.
Specifications of our models
Model |
Inlet Connection |
Outlet Connection (s) |
Inlet Flow Rate | Outlet Flow Rate | ||||
|---|---|---|---|---|---|---|---|---|
Size |
Type |
Qty |
Size |
Type |
Qty |
Nm3/h |
Nm3/h |
|
BAP 050 CP N |
½” |
BSPP |
1 |
⅜” |
BSPP |
4 |
85 |
85 |
BAP 050 CP H |
½” |
BSPP |
1 |
¼” |
Hansen |
4 |
85 |
85 |
BAP 050 CP S |
½” |
BSPP |
1 |
¼” |
Schrader |
4 |
85 |
85 |
BAP 100 CP N |
½” |
BSPP |
1 |
⅜” |
BSPP |
4 |
170 |
170 |
BAP 100 CP H |
½” |
BSPP |
1 |
¼” |
Hansen |
4 |
170 |
170 |
BAP 100 CP S |
½” |
BSPP |
1 |
¼” |
Schrader |
4 |
170 |
170 |
BAP 175 CP N |
½” |
BSPP |
1 |
⅜” |
BSPP |
4 |
297 |
297 |
BAP 175 CP H |
½” |
BSPP |
1 |
¼” |
Hansen |
4 |
297 |
297 |
BAP 175 CP S |
½” |
BSPP |
1 |
¼” |
Schrader |
4 |
297 |
297 |
Specifications |
BAP Panels |
|---|---|
Operating pressure range |
1 to 10 barg |
Recommended operating temperature range |
1.5 to 30°C |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
