F1 Performance Validated Filters

Filter Model

Replacement Element

Inlet & Outlet

Rated Flow ⁽¹⁾

NPT

scfm

Nm³/hr

NF - Coalescing, Particulate, or Activated Carbon

NF 0008 (grade)

E 0008 (grade)

¼”

8

13

NF 0015 (grade)

E 0015 (grade)

¼”

15

25

NF 0025 (grade)

E 0025 (grade)

¼”

25

42

NF 0030 (grade)

E 0030 (grade)

½”

30

48

NF 0035 (grade)

E 0035 (grade)

⅜”

35

59

NF 0050 (grade)

E 0050 (grade)

½”

50

85

NF 0070 (grade)

E 0090 (grade)

½”

70

119

NF 0085 (grade)

E 0090 (grade)

¾”

85

144

NF 0090 (grade)

E 0090 (grade)

1”

90

153

NF 00125 (grade)

E 0135 (grade)

¾”

125

212

NF 0135 (grade)

E 0135 (grade)

1”

135

229

NF 0175 (grade)

E 0175 (grade)

1”

175

297

NF 0280 (grade)

E 0325 (grade)

1 ¼”

280

476

NF 0290 (grade)

E 0325 (grade)

1 ½”

290

493

NF 0325 (grade)

E 0325 (grade)

1 ½”

325

550

NF 0400 (grade)

E 0450 (grade)

1 ½”

400

680

NF 0450 (grade)

E 0450 (grade)

2”

450

765

NF 0700 (grade)

E 0700 (grade)

2”

700

1190

NF 0850 (grade)

E 1000 (grade)

2 ½”

850

1445

NF 1000 (grade)

E 1000 (grade)

3”

1000

1700

NF 1250 (grade)

E 1250 (grade)

3”

1250

2125

NF 1500 (grade)

E 1500 (grade)

3”

1500

2550

NFD (Duplex) - 0.01 Micron Coalescing & Activated Carbon

NFD 25

E 0025 M01DAC

¼”

25

42

NFD 35

E 0035 M01DAC

⅜”

35

59

NFD 50

E 0050 M01DAC

½”

50

85

NFD 70

E 0085 M01DAC

½”

70

119

NFD 85

E 0085 M01DAC

¾”

85

144

NFD 125

E 0135 M01DAC

¾”

125

212

NFD 135

E 0135 M01DAC

1”

135

229

NFD 175

E 0175 M01DAC

1”

175

297

Specifications

NF 0008 to NF 0015

NF 0025 to NF 0050

NF 0070 to NF 1500

NFD 25 to NFD 50

NFD 70 to NFD 175

Design operating pressure range ⁽²⁾

0 to 232 psig

0 to 69 barg

0 to 232 psig

0 to 69 barg

22 to 232

1.5 to 69 barg

0 to 232 psig

0 to 69 barg

22 to 232

1.5 to 69 barg

NDK 0050

NDK 0050

NDK 1500

NDK 0050

NDK 1500

Differential pressure indicator / gauge

-

NDP 0050

NDP 1500

-

-

Specifications

M25

M5

M1

M01

AC

DAC

Maximum particle size (ISO class) ⁽³⁾

-

3

2

1

-

1

Maximum oil content (ISO class) ⁽³⁾

-

4

2

1

1

1

Particle removal (microns)

25

5

1

0.01

-

0.01

Max oil carry over at 68°F / 20°C (ppm or mg/m³)

10

5

0.1

0.01

0.003

0.003

Recommended operating temp range

35 to 176°F

2 to 80°C

35 to 176°F

2 to 80°C

35 to 176°F

2 to 80°C

35 to 176°F

2 to 80°C

35 to 77°F

2 to 25°C

35 to 77°F

2 to 25°C

Design operating temperature range

35 to 176°F

2 to 80°C

35 to 176°F

2 to 80°C

35 to 176°F

2 to 80°C

35 to 176°F

2 to 80°C

35 to 122°F

2 to 50°C

25 to 122°F

-4 to 50°C
