Refrigerated Compressed Air Dryers

nano aircel Non-Cycling Dryers

Introducing the revolutionary nano aircel brand of VF non-cycling refrigerated air dryers - the perfect solution for those who demand only the highest quality, dry compressed air for their manufacturing processes. This product has an unwavering focus on reliable and constant dew point performance in all flow conditions, making it highly dependable and energy-efficient. With its variable flow heat exchanger, the nano aircel non-cycling refrigerated air dryer allows for desired dew point performance, regardless of flow variations. Don't settle for anything less than the best - choose the nano aircel brand and experience the pinnacle of compressed air technology today! Trust the nano aircel non-cycling refrigerated air dryer to deliver the outstanding performance that your business deserves.

Key Specs:

Flow Rate

10 to 1200 scfm

Connection

½” NPT to 3” Flg

Air Quality

ISO 8573.1:2010 Class 5

Product Documentation

VF & DHT Series Non-Cycling and High Inlet Temperature Refrigerated Dryer Brochure

nano aircel VF Non-Cycling Refrigerated Dryers

Product Brochure

Filename
EN-VF-DHT-refrigerated-dryer-brochure.pdf
Size
1 MB
Format
pdf
View
ISO compressed air quality standards brochure

ISO Compressed Air Quality Standards Brochure

Support Brochure

Filename
EN-ISO-brochure-compressed-air-quality-standards.pdf
Size
7 MB
Format
pdf
View
F2003_16_2268KG5H4_53732394_SDS_GEN_US_en_9-1_US01.PDF

nano aircel VF Non-Cycling Refrigerated Dryers R134a Refrigerant

Material Safety Data Sheet

Filename
EN-AHLD-HLA-AEHD-ABP-BHD-AHCR-Rental-F200-.1875-SDS.pdf
Size
622 KB
Format
pdf
View

nano aircel VF Non-Cycling Refrigerated Dryers R404a Refrigerant

Material Safety Data Sheet

Filename
EN-VF-AES-refrigerated-dryers-R404a-MSDS.pdf
Size
485 KB
Format
pdf
View
nano aircel VF, DHT & AES Refrigerated Air Dryer User Guide Manual

VF Non-Cycling Refrigerated Dryers

User Guide

Filename
EN-VF-DHT-AES-user-guide-refrigerated-dryer.pdf
Size
3 MB
Format
pdf
View

Features

Plug-and-play design is fully packaged into a simple compact design, allowing these models to  fit into the smallest spaces.

Powder-coated steel panels for optimum corrosion resistance.

Pre- and after filter packages available to provide additional energy savings and improved air quality.

Specifications of our models

Dryer Model

Inlet &
Outlet

Rated Flow
at 100 psig

Absorbed Power

Standard
Power Supply (V/Ph/60Hz)
Refrigerant

NPT/FLG

scfm

kW

115/1

230/1

460/3

VF-10 ½” 10 0.29     R-134a
VF-15 ½” 15 0.29     R-134a
VF-25 ½” 25 0.29     R-134a
VF-40 ¾" 40 0.42     R-134a
VF-50 ¾" 50 0.42     R-134a
VF-60 ¾" 60 0.57     R-134a
VF-75 1" 75 0.83     R-134a
VF-100 1" 100 0.83     R-134a
VF-125 1" 125 1.05     R-134a
VF-150 1" 150 1.05     R-134a
VF-200 1 ½” 200 1.35     R-134a
VF-250 1 ½” 250 1.35     R-134a
VF-300 2" 300 1.99     R-134a
VF-400 2" 400 1.99     R-134a
VF-500 2" 500 2.53     R-134a
VF-600 3" 600 4.38     R-134a
VF-800 3" 800 4.38     R-134a
VF-1000 3" 1000 3.81     R-404a
VF-1200 3" 1200 6.25     R-404a

Specifications
Design operating pressure range 40 to 200 psig
Maximum inlet air temperature 120°F
Maximum ambient temperature 40°F  to 120°F

(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
