The High efficiency and initial low pressure drop of less than 0.5 psid means these units are utility rebate-friendly
Key Specs:
Flow Rate
250 to 5000 scfm
Connection
2” NPT to 6” Flg
Filtration
1 micron
- Brochures
- GA Drawings
Features
Design allows for serviceability without inlet & outlet disruptions
Mounted and piped differential pressure gauge, zero air loss drain, automatic vent ports and safety valve port included as standard
Specifications of our models
Filter Model |
Replacement Element |
Inlet & Outlet |
Rated Flow (1) |
|
Part No. |
NPT |
scfm |
Nm3/h |
|
E 0250 |
2” |
250 |
425 |
|
E 0500 |
3” |
500 |
850 |
|
E 1500 |
3” |
1000 |
1699 |
|
E 1500 |
3” Flg |
1250 |
2124 |
|
E 1500 |
4” Flg |
1500 |
2549 |
|
E 3000 |
4” Flg |
3000 |
5097 |
|
E 5000 |
6” Flg |
5000 |
8495 |
|
Specifications |
|
Recommended Operating Temperature Range |
69 to 180°F / 20 to 88°C |
Design Operating Temperature Range |
35 to 248°F / 2 to 120°C |
Design Operating Pressure Range |
20 to 150 psig / 1.5 to 10.3 bar |
Initial Differential Pressure |
Less than 0.5 psig / .03 bar |
Recommended Pressure Differential for Element Change |
1.0 psid / .07 bar |
Filtration Performance |
0.3 Micron @ 99.97% Efficiency |
ISO Air Quality Class (Solids, Water, Oil) |
ISO Class 2, 7, 3 |
(1) at 100 psig. For all other pressures, refer to the pressure correction factors above
(2) for condensate drain options, consult nano
(3) technical specifications subject to change without notice. Direct inquiries to [email protected] or contact 704.897.2182
