Wide range of flow rates for multiple user.
Key Specs:
Flow Rate
6 to 16 barg
Connections
3/8” to 2 ½” NPT (F)
Standards
EN12021
Product Documentation
- Brochures
- Certificates
- Electrical Diagram
- General Arrangement Drawings
- Material Safety Data Sheet
- Service Guides
- User Guides
- Worksheet
Features
With multiple connections for multiple users, the system contains 1 and 0.01 micron high-efficiency filter with drains, a 4-layer mixed bed to remove CO and scrub CO2 and an integral 1 micron particulate after filter.
Energy saving dew point control option provides the ultimate in energy and power savings.
Specifications of our models
Model |
Included Inlet Filtration |
Inlet & Outlet |
Inlet Flow Rate | Outlet Flow Rate |
|---|---|---|---|---|
Part no. |
PTC/BSPP |
Nm3/h |
Nm3/h |
|
NBA 030 |
GFNB 0015 M1/M01 |
⅜” PTC |
13 |
10 |
NBA 040 |
GFNB 0015 M1/M01 |
⅜” PTC |
20 |
15 |
NBA 050 |
GFNB 0025 M1/M01 |
⅜” PTC |
25 |
17 |
NBA 070 |
GFNB 0050 M1/M01 |
1” |
59 |
44 |
NBA 090 |
GFNB 0070 M1/M01 |
1” |
93 |
70 |
NBA 110 |
GFNB 0105 M1/M01 |
1” |
148 |
110 |
NBA 120 |
GFNB 0125 M1/M01 |
1” |
183 |
138 |
NBA 2110 |
GFNB 0280 M1/M01 |
2” |
292 |
219 |
NBA 2120 |
GFNB 0280 M1/M01 |
2” |
367 |
275 |
NBA 3120 |
GFNB 0325 M1/M01 |
2” |
550 |
413 |
NBA 4120 |
GFNB 0450 M1/M01 |
2” |
734 |
550 |
NBA 6120 |
GFNB 0700 M1/M01 |
2” |
1101 |
826 |
Specifications |
NBA 030 to 120 |
NBA 2110 to 6120 |
|---|---|---|
Operating pressure range |
6 to 16 barg |
6 to 10 barg |
Recommended operating temp range |
1.5 to 30°C |
1.5 to 30°C |
Recommended air inlet quality |
class 2 |
class 2 |
Design operating temperature range |
1.5 to 50°C |
1.5 to 50°C |
Power supply requirements |
85 to 264V AC, 50 or 60Hz |
100 to 240 VAC, 50 or 60Hz |
Power rating |
25W (NBA 030 to NBA 050) 35W (NBA 070 to NBA 120) |
38W |
Performance |
||
Maximum water content |
-31°C (pdp) |
-31°C (pdp) |
Maximum oil content |
0.01 mg/m3 |
0.01 mg/m3 |
Odour + taste |
none |
none |
O2 range |
21% + 1% |
21% + 1% |
Maximum CO content |
< 5 ppm |
< 5 ppm |
Maximum CO2 content |
< 500 ppm |
< 500 ppm |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
