100% tested for leaks, proper operation and dew point performance.
Key Specs:
Flow Rate
34 to 1110 scfm
Connection
1” to 2 ½” NPT (F)
Air Quality
ISO 8573.1:2010 Class 1.2.2
Product Documentation
- Brochures
- General Arrangement Drawings
- Material Safety Data Sheets
- Technical Papers
- User Guides
- Worksheets
Features
Compact design allows installation in spaces too small for a welded tower dryer.
Patented, high density snowstorm filled cartridges (models NDL 060 to NDL 130) with integrated after filter (all models 130) can be serviced in less than 15 minutes and provide maximum adsorption capacity.
Specifications of our models
Dryer Model |
Prefilter |
After Filter |
Inlet & Outlet |
Rated Flow at 100 psig |
|---|---|---|---|---|
NPT (F) |
scfm |
|||
D2 |
||||
NDL 060 GF PNU |
GF 0105 M01 |
integrated |
1” |
34 |
NDL 070 GF PNU |
GF 0105 M01 |
integrated |
1” |
41 |
NDL 080 GF PNU |
GF 0105 M01 |
integrated |
1” |
53 |
NDL 090 GF PNU |
GF 0105 M01 |
integrated |
1” |
66 |
NDL 100 GF PNU |
GF 0105 M01 |
integrated |
1” |
88 |
NDL 110 GF PNU |
GF 0125 M01 |
integrated |
1” |
106 |
NDL 120 GF PNU |
GF 0175 M01 |
integrated |
1” |
132 |
NDL 130 GF PNU |
GF 0175 M01 |
integrated |
1” |
177 |
D3 |
||||
NDL 2110 GF PNU |
GF 0450 M01 |
integrated |
2” |
212 |
NDL 2120 GF PNU |
GF 0450 M01 |
integrated |
2” |
276 |
NDL 2130 GF PNU |
GF 0450 M01 |
integrated |
2” |
400 |
NDL 3130 GF PNU |
GF 0700 M01 |
integrated |
2” |
560 |
NDL 4130 GF PNU |
GF 0850 M01 |
integrated |
2 ½” |
750 |
NDL 6120 GF PNU |
GF 0850 M01 |
integrated |
2 ½” |
828 |
NDL 6130 GF PNU |
GF 1250 M01 |
integrated |
2 1/2" |
1110 |
Specifications |
Standard |
Optional |
|---|---|---|
Maximum particle size (ISO class) |
class 2 (1 micron) |
class 1 (0.01 micron) |
Maximum water content (ISO class) |
class 2 (-40°F pdp) |
- |
Minimum operating pressure |
87 psig |
- |
Maximum operating pressure |
232 psig |
- |
Recommended operating temp range |
35 to 100°F |
- |
Design operating temperature range |
35 to 122°F |
- |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
