Custom engineered filter media designed to provide low air velocity preventing oil carry over for high efficiency filtration with minimal pressure drop
Key Specs:
Flow Rate
100 to 1330 Nm3/h
Connection
¼” to 2” BSPP
Filtration
25, 5, 1 & 0.01 micron &, AC & WS
Product Documentation
- Brochures
Features
Our quality models are manufactured from high grade 316 stainless steel
Stainless steel high pressure manual or stainless steel high pressure timed solenoid drains available to suit your condensate management requirements
Specifications of our models
Filter |
Replacement Element |
Inlet & Outlet |
Rated Flow at 50, 100 or 350 barg |
---|---|---|---|
Part No. |
BSPP |
Nm3/h |
|
N50SS (50 barg) |
|||
N50SS 0060 (grade) |
E50SS 0060 (grade) |
¼” |
100 |
N50SS 0120 (grade) |
E50SS 0120 (grade) |
⅜” |
200 |
N50SS 0200 (grade) |
E50SS 0200 (grade) |
½” |
340 |
N50SS 0300 (grade) |
E50SS 0300 (grade) |
¾” |
500 |
N50SS 0600 (grade) |
E50SS 0600 (grade) |
1” |
1000 |
N50SS 1000 (grade) |
E50SS 1200 (grade) |
1 ½” |
1700 |
N50SS 1200 (grade) |
E50SS 1200 (grade) |
2” |
2040 |
N50SS 2000 (grade) |
E50SS 2000 (grade) |
2” |
3400 |
N100SS (100 barg) |
|||
N100SS 0060 (grade) |
E100SS 0060 (grade) |
¼” |
100 |
N100SS 0185 (grade) |
E100SS 0185 (grade) |
½” |
315 |
N100SS 0270 (grade) |
E100SS 0270 (grade) |
¾” |
460 |
N100SS 0400 (grade) |
E100SS 0400 (grade) |
1” |
680 |
N100SS 0700 (grade) |
E100SS 0700 (grade) |
1” |
1200 |
N100SS 1000 (grade) |
E100SS 1000 (grade) |
1 ½” |
1700 |
N100SS 2000 (grade) |
E100SS 2000 (grade) |
2” |
3400 |
N350SS (350 barg) |
|||
N350SS 0028 (grade) |
E350SS 0028 (grade) |
¼” |
48 |
N350SS 0067 (grade) |
E350SS 0067 (grade) |
¼” |
111 |
N350SS 0150 (grade) |
E350SS 0150 (grade) |
½” |
255 |
N350SS 0300 (grade) |
E350SS 0300 (grade) |
¾” |
510 |
N350SS 0445 (grade) |
E350SS 0445 (grade) |
1” |
750 |
N350SS 0775 (grade) |
E350SS 0775 (grade) |
1” |
1330 |
Specifications |
NB50SS |
N100SS |
N350SS |
---|---|---|---|
Design operating pressure |
0 to 50 barg |
0 to 100 barg |
0 to 350 barg |
Condensate drain (included) |
manual ball valve |
||
Housing material |
315 stainless steel |
Element Performance |
M1 |
M01 |
AC |
|
---|---|---|---|---|
Particle removal |
1 micron |
0.01 micron |
- |
|
Max oil carryover at 20°C |
0.1 ppm |
0.01 ppm |
0.003 ppm |
|
Recommended operating temp range |
2 to 100°C |
2 to 100°C |
2 to 25°C |
|
Design operating temperature range |
2 to 120°C |
2 to 120°C |
2 to 50°C |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
