Two refrigerated cycling dryer sizes standing together, with the nano logo on the front

Refrigerated Compressed Air Dryers

Cycling Dryers

With savings up to 80% over a traditional dryer, the unique dry thermal mass in the nano NXC cycling refrigerated compressed air dryer takes power savings to the next level.  Matching power to actual demand and conditions, the NXC refrigerated compressed air dryer offers steady dew point performance, low pressure drop and reliable operation to ensure you have continuous, worry free, clean and dry compressed air. As a result, the energy saving cycling dryer is eligible for rebates in many parts of the country.

Key Specs:

Flow Rate

20 to 2000 scfm

Connection

 ½” NPT to 4” Flg

Product Grade

ISO 8573.1:2010 Class 4 - 6

R1 NXC - Brochure

R1 NXC Brochure - Cycling Refrigerated Dryers

Filename
UK-R1-NXC-brochure-cycling-refrigerated-dryers.pdf
Size
663 KB
Format
application/pdf
View
ISO compressed air quality standards brochure

ISO Brochure - Air Quality Standards

Filename
EN-ISO-brochure-compressed-air-quality-standards.pdf
Size
7 MB
Format
application/pdf
View
nano-purification solutions product brochure with equipment details

Safe Quality Food (SQF) Standards

Filename
EN-SQF-brochure-safe-quality-food-air-quality-standard.pdf
Size
848 KB
Format
application/pdf
View
nano equipment user guide

R1 NXC User Guide

Filename
R1-NXC-0020-2000-user-guide-manual-refrigerated-cycling-dryer.pdf
Size
3 MB
Format
application/pdf
View
equipment worksheet product technical paper

Refrigerated Dryer Worksheet

Filename
EN-R-series-worksheet-refrigerated-dryers.pdf
Size
186 KB
Format
application/pdf
View
ga general arrangement drawing

R1 NXC 0020-0045

Filename
R1-NXC-0020-0045-ga-general-arrangement-drawing-cyclin-refrigerated-dryers.pdf
Size
338 KB
Format
application/pdf
View
ga general arrangement drawing

R1 NXC 0065-0400

Filename
R1-NXC-0065-0400-ga-general-arrangement-drawing-cyclin-refrigerated-dryers.pdf
Size
386 KB
Format
application/pdf
View
ga general arrangement drawing

R1 NXC 500

Filename
R1-NXC-500-ga-general-arrangement-drawing-cyclin-refrigerated-dryers.pdf
Size
368 KB
Format
application/pdf
View
ga general arrangement drawing

R1 NXC 1050-1300

Filename
R1-NXC-1050-1300-ga-general-arrangement-drawing-cyclin-refrigerated-dryers.pdf
Size
428 KB
Format
application/pdf
View
ga general arrangement drawing

R1 NXC 1600-2000

Filename
R1-NXC-1600-2000-ga-general-arrangement-drawing-cyclin-refrigerated-dryers.pdf
Size
406 KB
Format
application/pdf
View
equipment electrical wiring diagram and electrical schematics

R1 NXC 0020 Electrical Drawing

Filename
R1-NXC-0020-electrical-wiring-schematics-refrigerated-dryer.pdf
Size
313 KB
Format
application/pdf
View
equipment electrical wiring diagram and electrical schematics

R1 NXC 0030-0045 Electrical Drawing

Filename
R1-NXC-0030-0045-electrical-wiring-schematics-refrigerated-dryer.pdf
Size
290 KB
Format
application/pdf
View
equipment electrical wiring diagram and electrical schematics

R1 NXC 0065-0090 Electrical Drawing

Filename
R1-NXC-0065-0090-electrical-wiring-schematics-refrigerated-dryer.pdf
Size
290 KB
Format
application/pdf
View
equipment electrical wiring diagram and electrical schematics

R1 NXC 0200-0400 Electrical Drawing

Filename
R1-NXC-0200-0265-0325-0400-230V-electrical-wiring-schematics-refrigerated-dryer.pdf
Size
271 KB
Format
application/pdf
View
equipment electrical wiring diagram and electrical schematics

R1 NXC 0500 - 0850 Electrical Drawing

Filename
R1-NXC-0500-0650-0850-electrical-wiring-schematics-refrigerated-dryer.pdf
Size
257 KB
Format
application/pdf
View
equipment electrical wiring diagram and electrical schematics

R1 NXC 1050-2000 Electrical Drawing

Filename
R1-NXC-1050-1300-1600-2000-electrical-wiring-schematics-refrigerated-dryer.pdf
Size
1 MB
Format
application/pdf
View

Features

R134a or R407C refrigerant and non-toxic silica dry mass utilized in all models

Easy to install, and start up with no overnight precooling of thermal mass required

Pre- and after filter packages available to provide additional energy savings and improved air quality

Specifications of our models

Dryer Model

Inlet & Outlet (1)

Rated Flow (2)

Absorbed Power (3)

Power Supply (V/Ph/60Hz) (4)

BSPP/FLG

scfm

Nm3/h

kW

115/1

230/1

460/3

NXC 0020

3/4"

18

30

0.21



NXC 0030

¾"

28

48

0.27



NXC 0045

¾"

41

70

0.28



NXC 0065

1"

59

100

0.63



NXC 0090

1"

82

140

0.66



NXC 0110

1"

103

175

0.68



NXC 0130

1 ½"

124

210

0.98



NXC 0165

1 ½"

153

260

1.02



NXC 0200

2"

177

300

1.05



NXC 0265

2"

247

420

1.32



NXC 0325

2”

318

540

1.37



NXC 0400

2"

388

660

1.41



NXC 0500

2 ½"

459

780

1.93



NXC 0650

3"

541

920

2.01



NXC 0850

3"

600

1020

2.38



NXC 1050

3"

812

1380

2.48



NXC 1300

3"

1271

2160

3.9



NXC 1600

4"

1519

2580

4.6



NXC 2000

4"

1860

3100

4.8



Specifications

Design operating pressure range

0 to 16 bar

Maximum inlet temperature

60°C

Maximum ambient temperature

43 to 50°C depending on refrigerant (contact support for details)

(1) 1⁄2” to 3” are NPT threaded connections, 4” are supplied with ANSI flanged connections

(2) rated flow capacity: conditions for rating dryers are in compliance with ISO7183 (Option A2). Compressed air at dryer inlet: 100 psig (7 bar) and 100°F (38°C); ambient air temperature: 100°F (38°C); operating on 60Hz power supply

(3) nominal absorbed power at rated operating conditions using 115/1/60 or 460/3/60 power supply (as applicable). for absorbed power at other voltages or conditions, contact support

(4) specify voltage requirements when ordering

(5) for 575V applications, please contact support

(6) to be used as a rough guide only. all applications should be confirmed by nano sizing software.

(7) for higher capacity requirements, please contact support
