Constructed with an oleophobic borosilicate microfiber media with an open cell reticulated foam prefilter.
Key specs:
FREE ASPIRATED AIR
1.7 to 212 Nm3/h
Connection
¼” to 3” BSPP
Filtration
0.01 micron
Product Documentation
- Brochures
Features
“Dead Stop” bowl feature provides full closure without over tightening.
Housing manufactured from cast aluminium alloy providing enhanced strength and feature an E-Coat™ finish for optimum internal and external corrosion protection.
Specifications of our models
Filter Model |
Replacement Element | Inlet & Outlet | Free Aspirated Air at 0.63 bara | Rarifed Air Flow |
|---|---|---|---|---|
| Part No. | BSPP | Nm3/h | Nm3/h | |
| GMVB 0025 | GE 0032 MV | ¼” | 1.7 | 3.4 |
| GMVB 0032 | GE 0032 MV | ⅜” | 3.4 | 6.8 |
| GMVB 0050 | GE 0050 MV | ½” | 6.8 | 17 |
| GMVB 0070 | GE 0105 MV | ½” | 12 | 31 |
| GMVB 0085 | GE 0105 MV | ¾” | 14 | 37 |
| GMVB 0105 | GE 0105 MV | 1" | 17 | 44 |
| GMVB 0175 | GE 0175 MV | 1" | 29 | 77 |
| GMVB 0280 | GE 0325 MV | 1 ¼” | 58 | 151 |
| GMVB 0325 | GE 0325 MV | 1 ½” | 63 | 167 |
| GMVB 0450 | GE 0450 MV | 2" | 66 | 175 |
| GMVB 0700 | GE 0700 MV | 2" | 93 | 246 |
| GMVB 0850 | GE 0900 MV | 2 ½” | 158 | 418 |
| GMVB 0900 | GE 0900 MV | 3" | 180 | 476 |
| GMVB 1250 | GE 01250 MV | 3" | 201 | 532 |
| GMVB 1500 | GE 1500 MV | 3" | 212 | 562 |
Specifications |
GMVB 0025 to GMVB 0050 |
GMVB 0070 to GMVB 1500 |
|---|---|---|
Design operating pressure range |
FV to 0.5 barg |
FV to 0.5 barg |
| Design operating temperature range | 1.7 to 60°C | 1.7 to 60°C |
Condensate drain |
GFMDKB 0050 | GFMDKB 1500 |
Differential pressure gauge |
- | GVDP 1500 |
Differential pressure indicator |
GVDP 0050 | - |
Element Performance |
MV |
|---|---|
Maximum particle size (ISO class) |
> 99.9999% (HTM 02-01 specifies > 99.995%) |
Pressure drop - clean |
≤ 0.39 barg |
Maximum element life |
6 months or 1000 hours |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
