These models have high performance valves designed for durability, ease of maintenance, and long service life.
Flow Rate
2 scfm and up
Connection
½” to 2 ½” NPT(F)
Air Quality
ISO 8573.1:2010 Class 1.1.2
Product Documentation
- Brochures
- Material Safety Data Sheets
- Technical Paper
- Worksheet
Features
The patented, high density snowstorm filled cartridges (models NDL 010 to NDL 130) with integrated after filter (all models) can be serviced in less than 15 minutes and provide maximum adsorption capacity
Energy Saving Dew Point Control, advanced PLC controller available on models NDL 2110 to NDL 6130
Specifications of our models
Dryer Model |
Stage 1 Prefilter |
Stage 2 Prefilter |
After Filter |
Inlet & Outlet |
Rated Flow at 100 psig |
|---|---|---|---|---|---|
| Part No | Part No. | Part No. | NPT (f) |
scfm |
|
D1 |
|||||
GF 0006 M1 |
GF 0006 M01 |
integrated |
½” PTC |
2 |
|
GF 0006 M1 |
GF 0006 M01 |
integrated |
½” PTC |
3 |
|
GF 0015 M1 |
GF 0015 M01 |
integrated |
½” PTC |
7 |
|
GF 0015 M1 |
GF 0015 M01 |
integrated |
½” PTC |
10 |
|
GF 0025 M1 |
GF 0025 M01 |
integrated |
½” PTC |
14 |
|
D2 |
|||||
GF 0105 M1 |
GF 0105 M01 |
integrated |
1” |
23 |
|
GF 0105 M1 |
GF 0105 M01 |
integrated |
1” |
28 |
|
GF 0105 M1 |
GF 0105 M01 |
integrated |
1” |
37 |
|
GF 0105 M1 |
GF 0105 M01 |
integrated |
1” |
46 |
|
GF 0105 M1 |
GF 0105 M01 |
integrated |
1” |
61 |
|
GF 0125 M1 |
GF 0125 M01 |
integrated |
1” |
74 |
|
GF 0175 M1 |
GF 0175 M01 |
integrated |
1” |
92 |
|
GF 0175 M1 |
GF 0175 M01 |
integrated |
1” |
124 |
|
D3 |
|||||
GF 0450 M1 |
GF 0450 M01 |
integrated |
2” |
148 |
|
GF 0450 M1 |
GF 0450 M01 |
integrated |
2” |
193 |
|
GF 0450 M1 |
GF 0450 M01 |
integrated |
2” |
280 |
|
GF 0450 M1 |
GF 0450 M01 |
integrated |
2” |
392 |
|
GF 0850 M1 |
GF 0850 M01 |
integrated |
2 ½” |
525 |
|
GF 0850 M1 |
GF 0850 M01 |
integrated |
2 ½” |
580 |
|
GF 0850 M1 |
GF 0850 M01 |
integrated |
2 ½” |
777 |
|
Specifications |
D1/D2 |
D3 |
||
|---|---|---|---|---|
standard |
optional |
standard |
optional |
|
Maximum particle size (ISO class) |
class 2 (1 micron) |
class 1 (0.01 micron) |
class 2 (1 micron) |
class 1 (0.01 micron) |
Maximum water content (ISO class) |
class 1 (-94°F pdp) |
class 2 (-40°F) |
class 1 (-94°F pdp) |
class 2 (-40°F) |
Minimum operating pressure |
58 psig |
- |
58 psig |
- |
Maximum operating pressure |
232 psig |
- |
232 psig |
- |
Recommended operating temp range |
35 to 85°F |
- |
35 to 85°F |
- |
Design operating temperature range |
35 to 100°F |
- |
35 to 100°F |
- |
Power supply requirements |
100 to 240 VAC / 50 or 60 Hz |
pneumatic or 24 V DC |
100 to 240 VAC / 50 or 60 Hz |
pneumatic or 24 V DC |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
