These models have high performance valves designed for durability, ease of maintenance, and long service life.
Key Specs:
Flow Rate
3.5 Nm3/h and up
Connection
⅜” PTC to 2 1/2” BSPP
Air Quality
ISO 8573.1:2010 Class 1.1.2
Product Documentation
- Brochures
- Material Safety Data Sheets
- Technical Papers
- Worksheets
Features
The patented, high density snowstorm filled cartridges (models NDL 010 to NDL 130) with integrated after filter (all models) can be serviced in less than 15 minutes and provide maximum adsorption capacity
Energy Saving Dew Point Control, advanced PLC controller available on models NDL 2110 to NDL 6130
Specifications of our models
Dryer Model |
Stage 1 Prefilter |
Stage 2 Prefilter |
After Filter |
Inlet & Outlet |
Flow Rate at 7 barg |
|---|---|---|---|---|---|
Part No. |
Part No. |
Part No. |
PTC/BSPP |
Nm3/h |
|
D1 |
|||||
NDL 010 LDP |
GFNB 0006 M1 |
GFNB 0008 M01 |
GFNB 0008 RM1 |
3/8” PTC |
3.5 |
NDL 020 LDP |
GFNB 0006 M1 |
GFNB 0006 M01 |
GFNB 0008 RM1 |
3/8” PTC |
5.9 |
NDL 030 LDP |
GFNB 0015 M1 |
GFNB 0015 M01 |
GFNB 0015 RM1 |
3/8” PTC |
11.9 |
NDL 040 LDP |
GFNB 0015 M1 |
GFNB 0006 M01 |
GFNB 0015 RM1 |
3/8” PTC |
18.2 |
NDL 050 LDP |
GFNB 0025 M1 |
GFNB 0006 M01 |
GFNB 0025 RM1 |
½” |
23 |
D2 |
|||||
NDL 060 LDP |
GFNB 0050 M1 |
GFNB 0050 M01 |
GFNB 0050 RM1 |
1” |
40 |
NDL 070 LDP |
GFNB 0050 M1 |
GFNB 0050 M01 |
GFNB 0050 RM1 |
1” |
49 |
NDL 080 LDP |
GFNB 0070 M1 |
GFNB 0070 M01 |
GFNB 0070 RM1 |
1” |
63 |
NDL 090 LDP |
GFNB 0070 M1 |
GFNB 0070 M01 |
GFNB 0070 RM1 |
1” |
78 |
NDL 100 LDP |
GFNB 0105 M1 |
GFNB 0105 M01 |
GFNB 0105 RM1 |
1” |
105 |
NDL 110 LDP |
GFNB 0175 M1 |
GFNB 0125 M01 |
GFNB 0125 RM1 |
1” |
126 |
NDL 120 LDP |
GFNB 0175 M1 |
GFNB 0175 M01 |
GFNB 0175 RM1 |
1” |
157 |
NDL 130 LDP |
GFNB 0175 M1 |
GFNB 0175 M01 |
GFNB 0175 RM1 |
1” |
210 |
D3 |
|||||
NDL 2110 LDP |
GFNB 0280 M1 |
GFNB 0280 M01 |
GFNB 0280 RM1 |
2” |
252 |
NDL 2120 LDP |
GFNB 0280 M1 |
GFNB 0280 M01 |
GFNB 0280 RM1 |
2” |
328 |
NDL 2130 LDP |
GFNB 0450 M1 |
GFNB 0450 M01 |
GFNB 0450 RM1 |
2” |
476 |
NDL 3130 LDP |
GFNB 0700 M1 |
GFNB 0700 M01 |
GFNB 0700 RM1 |
2” |
666 |
NDL 4130 LDP |
GFNB 0850 M1 |
GFNB 0850 M01 |
GFNB 0850 RM1 |
2 ½” |
892 |
NDL 6120 LDP |
GFNB 0850 M1 |
GFNB 0850 M01 |
GFNB 0850 RM1 |
2 ½” |
985 |
NDL 6130 LDP |
GFNB 1250 M1 |
GFNB 1250 M01 |
GFNB 1250 RM1 |
2 ½” |
1320 |
Specifications |
D1/D2 |
D3 |
||
Standard |
Optional |
Standard |
Optional |
|
Maximum particle size (ISO class) |
- |
- |
class 2 (1 micron) |
class 1 (0.01 micron) |
Maximum water content (ISO class) |
class 1 (-70°C pdp) |
class 2 (-40°C) |
class 1 (-70°C pdp) |
class 2 (-40°C) |
Minimum operating pressure |
6 barg |
- |
6 barg |
- |
Maximum operating pressure |
16 barg |
- |
10 barg |
consult factory |
Recommended operating temp range |
1.5 to 30°C |
- |
2 to 30°C |
- |
Design operating temperature range |
1.5 to 30°C |
- |
2 to 30°C |
- |
Power supply requirements |
85 to 264V AC, / 50/60 Hz |
24V DC |
85 to 264V AC, / 50/60 Hz |
24V DC |
Power rating |
25W (D1) 35W (D2) |
- | 35W |
- |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
