These models have high performance valves designed for durability, ease of maintenance, and long service life.
Key Specs:
Flow Rate
2 scfm and up
Connection
⅜” PTC to 2 ½” NPT (F)
Air Quality
ISO 8573.1:2010 Class 1.1.2
Product Documentation
- Brochures
- Certificates
- Electrical Diagrams
- General Arrangement Drawings
- Material Safety Data Sheets
- P & ID
- Service Intervals
- Service Manuals
- Spare Parts Guide
- Technical Papers
- User Guides
- Worksheets
Features
The patented, high density snowstorm filled cartridges (models NDL 010 to NDL 130) with integrated after filter (all models) can be serviced in less than 15 minutes and provide maximum adsorption capacity
Energy-saving dew point control and a -94°F pressure dew point are optional features available on all models, from NDL 010 to NDL 6130. The advanced PLC controller option is only available for models NDL 2110 through NDL 6130.
Specifications of Our Models
Modular Desiccant Dryer Model |
Stage 1 Prefilter |
Stage 2 Prefilter |
After Filter |
Inlet & Outlet |
Rated Flow at 100 psig |
|---|---|---|---|---|---|
| Part No | Part No. | Part No. | NPT (f) |
scfm |
|
D1 |
|||||
| integrated | ⅜" PTC |
2 |
|||
| integrated | ⅜" PTC |
3 |
|||
integrated |
⅜" PTC |
7 |
|||
integrated |
⅜" PTC |
10 |
|||
integrated |
½” PTC |
14 |
|||
D2 |
|||||
NDL 060 GF2 LDP |
GFN 0105 M1 |
GFN 0105 M01 |
integrated |
1” |
23 |
NDL 070 GF2 LDP |
GFN 0105 M1 |
GFN 0105 M01 |
integrated |
1” |
28 |
NDL 080 GF2 LDP |
GFN 0105 M1 |
GFN 0105 M01 |
integrated |
1” |
37 |
NDL 090 GF2 LDP |
GFN 0105 M1 |
GFN 0105 M01 |
integrated |
1” |
46 |
NDL 100 GF2 LDP |
GFN 0105 M1 |
GFN 0105 M01 |
integrated |
1” |
61 |
NDL 110 GF2 LDP |
GFN 0125 M1 |
GFN 0125 M01 |
integrated |
1” |
74 |
NDL 120 GF2 LDP |
GFN 0175 M1 |
GFN 0175 M01 |
integrated |
1” |
92 |
NDL 130 GF2 LDP |
GFN 0175 M1 |
GFN 0175 M01 |
integrated |
1” |
124 |
D3 |
|||||
NDL 2110 GF2 LDP |
GFN 0450 M1 |
GFN 0450 M01 |
integrated |
2” |
148 |
NDL 2120 GF2 LDP |
GFN 0450 M1 |
GFN 0450 M01 |
integrated |
2” |
193 |
NDL 2130 GF2 LDP |
GFN 0450 M1 |
GFN 0450 M01 |
integrated |
2” |
280 |
NDL 3130 GF2 LDP |
GFN 0450 M1 |
GFN 0450 M01 |
integrated |
2” |
392 |
NDL 4130 GF2 LDP |
GFN 0850 M1 |
GFN 0850 M01 |
integrated |
2 ½” |
525 |
NDL 6120 GF2 LDP |
GFN 0850 M1 |
GFN 0850 M01 |
integrated |
2 ½” |
580 |
NDL 6130 GF2 LDP |
GFN 0850 M1 |
GFN 0850 M01 |
integrated |
2 ½” |
777 |
Specifications |
D1/D2 |
D3 |
||
|---|---|---|---|---|
standard |
optional |
standard |
optional |
|
Maximum particle size (ISO class) |
class 2 (1 micron) |
class 1 (0.01 micron) |
class 2 (1 micron) |
class 1 (0.01 micron) |
Maximum water content (ISO class) |
class 1 (-94°F pdp) |
class 2 (-40°F) |
class 1 (-94°F pdp) |
class 2 (-40°F) |
Minimum operating pressure |
58 psig |
- |
58 psig |
- |
Maximum operating pressure |
232 psig |
- |
232 psig |
- |
Recommended operating temp range |
35 to 85°F |
- |
35 to 85°F |
- |
Design operating temperature range |
35 to 100°F |
- |
35 to 100°F |
- |
Power supply requirements |
100 to 240 VAC / 50 or 60 Hz |
pneumatic or 24 V DC |
100 to 240 VAC / 50 or 60 Hz |
pneumatic or 24 V DC |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
