Regeneration circuit is fully insulated for maximum efficiency, and specifically designed for a long and dependable operating life in harsh industrial environments.
Key Specs:
Flow Rate
250 to 6000 scfm
Connection
1½” to 8” Flg
Air Quality
ISO 8573.1:2010
Product Documentation
- Brochures
- General Arrangement Drawings
- Material Safety Data Sheets
- Worksheets
- Spare Parts Lists
Features
Utilizes atmospheric air for regeneration, making for easy maintenance. Also includes a rugged construction with TEFC premium motor that includes filtered air intake.
ASME code pressure vessels, UL/cUL compliant, made in the USA activated alumina, lifting lugs and/or fork lift pockets.
Specifications of Our Models
Blower Purge Desiccant Dryer Model |
Mounted Pre & After Filtration as Standard |
Inlet & Outlet |
Rated Flow at 100 psig |
Heater |
|
|---|---|---|---|---|---|
Prefilter |
After Filter |
NPT/Flg |
scfm |
kW |
|
BP 0250 |
GFN0325M01 | GFN0325M1 | 1½" NPT | 250 | 6 |
| BP 0350 | GFN0450M01 | GFN0450M1 | 2" NPT | 350 | 8 |
| BP 0500 | GFN0700M01 | GFN0700M1 | 2" NPT | 500 | 11 |
| BP 0600 | GFN0700M01 | GFN0700M1 | 2" NPT | 600 | 14 |
| BP 0800 | GFN0900M01 | GFN0900M1 | 3" Flg | 800 | 18 |
| BP 1000 | GFN1250M01 | GFN1250M1 | 3" Flg | 1000 | 22 |
| BP 1200 | GFN1250M01 | GFN1250M1 | 3" Flg | 1200 | 27 |
| BP 1400 | GFN1500M01 | GFN1500M1 | 4" Flg | 1400 | 32.5 |
| BP 1600 | NFZ2500M01 | NFZ2500M1 | 4" Flg | 1600 | 37 |
| BP 2000 | NFZ2500M01 | NFZ2500M1 | 4" Flg | 2000 | 45 |
| BP 2500 | NFZ2500M01 | NFZ2500M1 | 4" Flg | 2500 | 52 |
| BP 3000 | NFZ3500M01 | NFZ3500M1 | 6" Flg | 3000 | 64 |
| BP 3500 | NFZ3500M01 | NFZ3500M1 | 6" Flg | 3500 | 78 |
| BP 4000 | NFZ4000M01 | NFZ4000M1 | 6" Flg | 4000 | 90 |
| BP 5000 | NFZ5000M01 | NFZ5000M1 | 6" Flg | 5000 | 110 |
| BP 6000 | NFZ7500M01 | NFZ7500M1 | 8" Flg | 6000 | 130 |
Specifications |
Standard |
Optional |
|---|---|---|
Maximum particle size (ISO class) |
class 2 (1 micron) |
class 1 (0.01 micron) |
Maximum water content (ISO class) |
class 2 (-40°F pdp) |
- |
Minimum / design / maximum operating pressure range |
(Models BP 0250 to BP 1200) 60 psig / 100 psig / 180 psig (Models BP 1400 to BP 6000) 60 psig / 100 psig / 135 psig |
CF |
Minimum / design / maximum ambient temperature |
38°F / 100°F/ 120°F | - |
Minimum / design / maximum inlet temperature |
38°F / 100°F/ 120°F | - |
Power supply requirements |
460 VAC / 60 Hz |
230 VAC / 60 Hz |
(1) This information is for general information purposes only. For additional technical specifications, refer to the product brochure, technical data sheets, and/or user guides. Technical specifications are subject to change.
